RIDGID SWAGGING TOOL 52420

The  RIDGID 52420

 (Model 570) is a professional-grade, 4-piece swaging tool kit designed to expand the ends of soft metal tubing (copper, aluminum, or brass). This process allows one tube to be joined to another of the same size without the need for additional fittings, creating a deeper, flute-shaped expansion suitable for permanent soldered or brazed connections.

• Kit Contents: Includes four individual swaging tools and a handy vinyl pouch for storage.
• Size Capacity: Covers common tubing diameters in both inch and metric:
  • 1/4" (6 mm)
  • 3/8" (10 mm)
  • 1/2" (12 mm)
  • 5/8" (16 mm)
• Build Quality: Tools are zinc-plated for enhanced durability, accuracy, and corrosion resistance.
• Operation Type: These are manual, hammer-driven tools. You insert the tool into the tube and strike it with a hammer to gradually expand the material from the inside out.
• Weight: The entire kit weighs approximately 0.45 kg (1 lb).
